9DMX CHANNELSChannel FunctionValueDescription1Pan0-255PAN Movement (0-540°)2Pan Fine0-255Fine control of Pan movement3Tilt0-255Tilt Movement (0-270°)4Tilt Fine0-255Fine control of Tilt movement5Speed0-255Speed control of PAN/TILT movement0-031White032-063Red6Color064-095GreenWheel096-127Blue128-191Infinite forward rotation from slow to fast192-255Infinite backward rotation from slow to fastLEN0-200Beam effect from close to open7Rotation201-255Infinite LEN rotation from slow to fast( on and on open and close for beam effect)8Dimmer0-2550-100% Linear dimmer from dark to bright0-003No function9Strobe004-095Strobe effect from slow to fast (1-25Hz)096-176Random strobe effect177-255Pulse strobe effect10LED 10-2550-100% Linear LED 1 dimmer from dark to bright11LED 20-2550-100% Linear LED 2 dimmer from dark to bright12LED 30-2550-100% Linear LED 3 dimmer from dark to bright13LED 40-2550-100% Linear LED 4 dimmer from dark to bright0-049CH1-CH13 activated050-074Internal program 1 from slow to fast14Internal075-099Internal program 2 from slow to fastProgram100-149Internal program 3150-199Internal program 4200-255Internal program 50-099No function15Reset100-250Auto running251-255Reset in 3s

• Bis zu 50000 Stunden Lebenserwartung

• Intelligentes und Hocheffizientes Optisches System

• 4 individuelle Beams mit können zwischen 40° und 5° bewegt werden

• Farbrad mit R, G, B und W• Schnelle und leise PAN (540°)/TILT(270°) Bewegungen

• Automatische Positionskorrektur• 0-100% linearer Dimmer

• Flicker free

• 0-25Hz Strobe und Random Strobe

• Interne automatik Progamme

• 15 DMX512 Kanäle

• DMX 512, master-slave, automatik und Sound to Light

• Blaues LCD-Display• Powercon IN/OUT

• 3-pin XLR IN/OUT• -35°C-45°C Umgebungstemperatur

• IP20

• Stabiler MontagebügelTechnische DatenSpannung:90-260V 50/60HzLED´s:4 x 25W Weißlicht LEDSteuerung:DMX512, master-slave and sound activated or auto operationDMX-Kanäle:15Leistungsaufnahme:130WAbmessungen: : :185mm x 270mm x 370mmGewicht:7kg
